额定电流(rating)：3A-30A

输入电压(Input Power)：12VDC/24VDC 50-60Hz

耐电压强度(Withstand voltage strength)：1500VAC/1min，漏电电流≤0.5mA

(1500VAC/min,the leaked current is less than≤0.5mA)

绝缘电阻(Insulation Resistance)：500VDC 1Min≥100MΩ

额定短路能力(Rated short-circuit capacity)：125VAC/1000A，250VAC/1000A

额定通断能力(Rated breaking capacity)：6倍额定电流

（6 times rated current)

复位方式(Reset)：自动复位(Auto Reset)

复位时间(Reset Time)：60s”内回复(Within 60s”)
